What are the three thermodynamic electricity storage technologies?
In this paper, three thermodynamic electricity storage technologies, namely CAES, CCES and PTES, are comprehensively reviewed. For each technology, the basic principle is firstly clarified and then system structures and storage devices are summarized. Thereafter, the corresponding demonstrations and costs of different routes are sorted out.
What is thermodynamic energy storage?
Thermodynamic electricity storage adopts the thermal processes such as compression, expansion, heating and cooling to convert electrical energy into pressure energy, heat energy or cold energy for storage in the low period of power consumption, and then convert the stored energy into electrical energy at the peak of electricity consumption.
Does thermodynamic electricity storage depend on water resources?
On the contrary, thermodynamic electricity storage does not depend on water resources, and can be used as a supplement or substitute for PHES stations. Meanwhile, it should be noted that thermodynamic electricity storage is often accompanied by the storage and release of cold energy and heat energy.
How does storage pressure affect round-trip efficiency in SC-CCES system?
However, the pressures of two storage tanks in SC-CCES system are high, and the storage pressure on the high-pressure side is difficult to improve due to the system security restrictions. Therefore, the input and output of power in the processes of compression and expansion are limited, thus affecting the improvement of round-trip efficiency.
Which thermodynamic electricity storage technology is most suitable for long-term storage?
Compared to other storage technologies, the thermodynamic electricity storage technology represented by CAES, CCES and PTES is more suitable for large-scale and long-term storage. In recent years, CAES, CCES and PTES technologies have been widely investigated and vigorously developed.
What are the different types of energy storage systems?
Depending on the form of energy storage, energy storage systems can be categorized into three types which are heat storage technology, cold storage technology and electricity storage technology. While heat and cold energy can be used directly, this is limited to the user side.
